A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
  • A Grade Agate Jar Ceramic Ball Mill Jar For Grinding
A Grade Agate Jar Ceramic Ball Mill Jar For Grinding

A Grade Agate Jar Ceramic Ball Mill Jar For Grinding

Place of Origin Hunan, China
Brand Name Kingda
Model Number 50ML-3L
Product Details
Application:
Industrial Ceramic
Processing Service:
Bending, Welding, Cutting, Punching, Decoiling, Moulding, Grinding, Miling
Color:
Natural Colors
Dimension(L*W*H):
45*45*45
Name:
Agate Grinding Ball
Density:
2.65g/cm3
Industry Characteristics:
Grinding
Hardness:
7.2 -7.5 Mohs'
Applied Fields:
Ink,coating, Painting,mineral,magnetic...
Certificate:
ISO9001:2008/ROHS
Highlight:

agate ball milling jar

,

Ceramic Ball Mill Jar

,

A Grade Ceramic Ball Mill Jar

Payment & Shipping Terms
Minimum Order Quantity
1 PC
Price
Negotiable
Packaging Details
PE Foam + Cartons / Wooden cases
Delivery Time
3-7 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
5000 pcs / Month
Product Description

Agate Grinding Jar/ Ball Mill Grinding Jars/Zirconia Ball Mill Ceramic Jars

Agate Grinding Jar


KINGDA High purity natural Brazilian agate grinding jars, highly wear-resistant and resistant to acids (except HF), with advantages of no impurities, no cracks, glossy, high-quality, strong vibration resistance. After experiments, it shows that the item have no cracks, no bump after high-speed vibration abrasion.




Features:
1.No impurities, no crack, high gloss, resistance to strong shaking force. Experiment has proved that after high speed vibration and wearing, agate jar has no crack or no bump phenomenon.
2.Kingda agate mill jar is made of Brazil and Uruguay agate nature raw material with bright color and high hardness.
3.With characteristics of high temperature resistance, strong acid resistance and alkali resistance. Agate mill jar can be used in the acid grinding media.
Description:
KINGDA High purity natural Brazilian agate grinding jars, highly wear-resistant and resistant to acids (except HF), with advantages of no impurities, no cracks, glossy, high-quality, strong vibration resistance. After experiments, it shows that the item have no cracks, no bump after high-speed vibration abrasion.
We can customize various types of vacuum jar according to customer's needs.



Product Paramenters
Material:
Natural agate


Density:
2.65 g/cm3


Hardness
7.2 -7.5 Mohs'


Volume:
50 - 2000 mL


Colour:
Natural agate color


Suitable for:
Soft to medium-hard samples


Attachments:
Lid, silicon sealing gasket


Applications:
Grinding / mixing / ball milling


Comments:
• Contamination free for samples
• Do not heat
• Can be customized for various ball milling equipments, such as Retsch series, ect







 Specification Parameters:







Volume of Jar
Outside Diameter
(mm)
Inner Diameter
(mm)
Inner Depth
(mm)
Height of without lid
(mm)
Total Height
(mm)
50ml
65
45
37
49
58
100ml
73
50
52
62
70
150ml
90
62
55
70
80
250ml
93
73
70
80
90
400ml
105
82
80
93
103
500ml
104
86
90
100
108
1L
133
107
114
126
140
1.5L
167
137
103
118
133
2L
156
130
155
 170
188
Remarks: 1. Size deviation within ±2mm; 2. Agate covered 1mm stainless steel outside as per request.












 A Grade Agate Jar Ceramic Ball Mill Jar For Grinding 0

A Grade Agate Jar Ceramic Ball Mill Jar For Grinding 1
A Grade Agate Jar Ceramic Ball Mill Jar For Grinding 2
A Grade Agate Jar Ceramic Ball Mill Jar For Grinding 3



Main advantage


1.It is one of biggest manufacture to make ceramic grinding media ball in China.

2.SGS, ROHS certificate,Strict quality control system ISO 9001.

3.Professional,Sincerity,Concentration,Honesty,Constant striving for improvement,Mutual Glory.

4.High Quality raw material imported from Australian.

5. Quick-delivery, safe packing
FAQ
1.Q:What's product your company supply?
A.We can supply yttrium stab.zirconia bead,cerium stab.zirconia bead,zirconia silicate bead,high alumina ball, agate ball,tungstern carbide ball, ball mill grinding jar,tungsten carbide ball, zirconium powder,ceramic structual elements etc.

2. Q: What is your MOQ?
A: 1KG. We accept smaller quantity but price is higher.

3. Q: Can you provide free samples?
A: Yes, the buyers just afford shipping cost .

4. Q: What is your production time for bulk order?
A: 7~30 days, according to order quantity.

5. Q: What is your normal package?
A: Woven bag or barrel ,drum,carton box and pallet.

6. Q: What is your payment term?
A: T/T 30%-70% Deposit, balance against copy of B/L.
L/C at sight,Western Union, paypal,Visa,etc.
