Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
  • Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
  • Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
  • Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
  • Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
  • Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design
Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design

Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design

Place of Origin Hunan, China
Brand Name Kingda
Model Number 50ML-3L
Product Details
Output (kg/h):
1 - 10 Kg/h
Feeding Size (mm):
1 - 50 Mm
Output Size (mesh):
125000mesh
Material:
Zirconium
Application:
Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing, Abrasive Refractory Ceramic Industry
Condition:
New
Hardness:
9 Mohs
Size:
50ML-3L
Highlight:

Nano Powder Grinding Zirconia Jar

,

125000mesh Zirconia Jar

,

Lab Ball Mill Zirconia Jar

Payment & Shipping Terms
Minimum Order Quantity
1 PC
Price
Negotiable
Packaging Details
PE Foam + Cartons / Wooden cases
Delivery Time
3-7 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
5000 pcs / Month
Product Description

China Supplier ceramic zirconia grinding  jar

Product Description

Highly polished YSZ (Yttrium stabilized ZrO2) zirconium oxide jars, 60 times the hardness of regular steel, highly wear-resistant and resistant to acid and solvents. The grinding jars are extensively applied on in the fields of Paint, Ink,Coating, Geology, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry, Medicine, Environmental Protection and so on. Each jar set includes grinding jar, jar lid, rubber sealing gasket and different sizes of mixed zirconium oxide grinding balls.





      Composition

(%)

Specific Gravity

(G/CM3)

Bulk Density

(Kg/L)

Capacity

(ML)

ZrO2: 95± 0.2

Y2O3: 5± 0.2

 ≥ 6.02   ≥3.7

50;100;250;

500;1000;2000;3000
Dimesion (offer OEM & ODM Service)
 Jar  Volume  OD (mm)  ID (mm)  Total Height (mm)
 50ml  55  38  67
 100ml  65  50  75
 250ml  92  74  88
 500ml  100  84  118
 1000ml  128  108  148
 2.0L  158  138  162
 3.0L  158  138  220
Note: Jar size of each patch will control  tolerance ±2mm. One set includes: jar + lid + sealing gasket.

Choice of Grinding Jars & Grinding Balls

In order to prevent excessive abrasion, the hardness of the grinding jars used and of the grinding balls must be higher than that of the material used. Normally, grinding jars and grinding balls of the same material should be chosen.



Features:
1. High specific gravity, high efficiency
2. Highly wear resistant to acid and solvents
3. High cost-effective, low wear and long lifetime
4. Highly polished, smooth, easy to clean, low abrasion to the equipment
5. High mechanical strength, good toughness, impact resistance, no broken beads
6. Mainly used for lab planetary ball mill machines

Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design 0





Application Fields:

 Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design 1



Our Services



Zirconia Jar for Lab Ball Mill Nano Powder Grinding Output Size mesh 125000mesh Design 2



FAQ



1.What's product your company supply?

  A.We can supply yttrium stab.zirconia bead,cerium stab.zirconia bead,zirconia silicate  bead,high alumina ball, agate ball, ball mill grinding jar, tungsten carbide ball, zirconium powder,ceramic structual elements etc.



 2. Q: What is your MOQ?
 A: 1KG. We accept smaller quantity but price is higher.



 3. Q: Can you provide free samples?
 A: Yes, the buyers just afford shipping cost .



 4. Q: What is your production time for bulk order?
 A: 7~30 days, according to order quantity.



 5. Q: What is your normal package?
 A: Woven bag or barrel ,drum,carton box and pallet.



 6. Q: What is your payment term?
 A: T/T 30%-70% Deposit, balance against copy of B/L.

 L/C at sight,Western Union, paypal,Visa,etc
