Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding
  • Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding
  • Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding
  • Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding
  • Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding
  • Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding

Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding

Place of Origin Hunan, China
Brand Name Kingda
Model Number 0.1-50MM
Product Details
Application:
Industrial Ceramic, Industrial Ceramic, Inks,paintings,TiO2,CaCO3,paper Pulps,cosmet Etc.
Material:
Zirconia Ceramic
Product Name:
Zirconia Grinding Micron Ball For Paints Milling Beading Machine
Moh's Hardness:
>9
Bulk Density:
3.7gcm3
Abrasion:
<5ppmh
Specific Density:
6.02gcm3
Advantages:
Narrow Size Distribution,ultrafine Grinding
Vicker Hardness:
>1150
Usage:
Suferfine Disperisng And Grinding
Size:
0.1--55mm
Port:
Shanghai, Guangzhou,shenzhen
High Light:

Industrial Zirconia Milling Beads

,

Zirconia Milling Beads

,

Zirconia Milling Balls

Payment & Shipping Terms
Minimum Order Quantity
1 KG
Price
Negotiable
Packaging Details
25KG/drum / 500-1000KG on pallet with shrink wrapped
Delivery Time
3-7 Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
10 Ton / Month
Product Description

 zirconia Shinny Microbead Grinding Micron Ball For Paints Milling Beading Machine


Product Description



Chemical Composition:

≥ ZrO2: 94.8%



≥ Y2O3+ Others : 5.2%

Specific Gravity:

≥ 6.0 2g/cm3

Bulk Gravity:

3.7g/cm3

Flexibility factor:

8.0Mpa.m1/2

Hardness(Mohs)

9

Crushing strength:

150kgf(2mm)

Wear value:

< 0.01%

Sphere size (mm)  : Φ0.08, Φ0.1, Φ0.2, Φ0.3, Φ0.4, Φ0.5, Φ0.6, Φ0.8, Φ1, Φ1.5, Φ2, Φ2.5, Φ3,Φ4, Φ5, Φ6, Φ7, Φ8, Φ10, Φ12, Φ15, Φ20, Φ25, Φ30, Φ40, Φ50;

Cylinder size (mm) : 3*3, 5*5, 7*7, 10*10, 12.7*12.7, 15*15
Photo show:
Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding 0
40times under microscope for 0.3mm YSZ ball








Features:

u High density, high grinding efficiency, high hardness;

u Compact Tetragonal Zirconia Polycrystalline (YTZP) to give the beads outstanding anti- corrosion and wear resistance;

u Always keep the smooth surface and the good roundness.



Kingda TZP zirconia grinding beads have uniform microstructure from inside to outside.

We have unique ways in control product microstructure crystalling phase .Scanning electron microscopy showed,

beads microstructure is almost the same as that of Japan TOSOH company similar product.

Application Fields:



   1.  Painting,Ink,Coating

   2.  Ceramic Inks & Electronic Paste

   3.  Refractory materials,Magnetic materials

        Dye,Pigment,Textile,Printing

   4. Cosmetics & Medicine,Agrochemical

   5.  Mine industry(Gold, Silver,   Nickel, Zinc and Lead,etc.)



Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding 1



Industrial Zirconia Milling Beads / Balls Shinny Microbead Grinding 2



FAQ



1.What's product your company supply?

  A.We can supply yttrium stab.zirconia bead,cerium stab.zirconia bead,zirconia silicate  bead,high alumina ball, agate ball,tungsten carbide ball, ball mill grinding jar, tungsten carbide ball, zirconium powder,ceramic structual elements etc.



 2. Q: What is your MOQ?
 A: 1KG. We accept smaller quantity but price is higher.



 3. Q: Can you provide free samples?
 A: Yes, the buyers just afford shipping cost .



 4. Q: What is your production time for bulk order?
 A: 7~30 days, according to order quantity.



 5. Q: What is your normal package?
 A: Woven bag or barrel ,drum,carton box and pallet.



 6. Q: What is your payment term?
 A: T/T 30%-70% Deposit, balance against copy of B/L.

 L/C at sight,Western Union, paypal,Visa,etc
