| Place of Origin: | Hunan, China |
|---|---|
| Brand Name: | Kingda |
| Certification: | CE ISO |
| Model Number: | KD-XQM-2L |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiable |
| Packaging Details: | PE Foam + Cartons / Wooden cases |
| Delivery Time: | 3-7 Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 1000 Set / Month |
| Working Style: | High-speed Universal | Power Source:: | Electricity |
|---|---|---|---|
| Power Supply:: | 110V-60Hz Or 220-50Hz 0.32kw | Matchable Jar Volume:: | 0.2-200ml |
| Feeding Size (mm): | 1 - 100 Mm | Rotation Speed:: | 90-870 Rpm |
| Application: | Grinding / Polishing / Despersing | Warranty: | 1 Year |
| After Warranty Service:: | Video Technical Support | Packing: | PE Foam + Cartons / Wooden Cases |
| Customization:: | Available | ||
| High Light: | Lab Agate Jar,Grinding Agate Jar |
||
Product Description————————
Horizontal Design for Enhanced Mixing:
The horizontal orientation ensures efficient mixing and grinding, providing optimal results in sample preparation.
High Efficiency with Small Footprint: Despite its compact design, this machine delivers high efficiency, making it an ideal choice for laboratories where space is at a premium.
Efficient Grinding:
Powered by a 220V motor, this laboratory equipment ensures efficient grinding of samples to achieve desired particle sizes. It is ideal for various applications, including research, material analysis, and product development.
User-Friendly Interface: The machine features a user-friendly interface, allowing researchers to easily adjust parameters, monitor the milling process, and maintain control over experiments.
Versatility in Application:
Whether you are working with ceramics, minerals, or other materials, our ceramic ball mill provides a versatile solution for your grinding needs. Achieve precise results in a controlled laboratory environment.
Application————————
1. Materials Research and Development:
The Vertical Planetary Ball Mill plays a crucial role in the mixing, fine grinding, and new product development of high-tech materials. Researchers can utilize its ability for small batch production, swiftly obtaining samples with high purity and precise particle size.
2. Ceramic and Chemical Engineering Research:
The machine finds applications in ceramic and chemical engineering research, providing researchers with a tool for grinding and mixing materials with precision.
Technical Specifications————————
| Drive Mode | gear drive / belt drive |
|---|---|
| Operation Mode | 2 / 4 grinding tanks working together |
| Maximum Loading Capacity | 2/3 of the capacity of milling tank |
| Feeding Granularity | soil material ≤10mm, other materials ≤3mm |
| Output Granularity | Minimum 0.1um |
| Rotational speed ratio | 1:2 (0.4L,2L,4L); 1:1.5(12L,20L) |
| Rotation Speed | 0.4L:0~600rounds/min; 2L:0~580rounds/min 4L:0~530rounds/min 20L:0-280 rounds/min |
| Speed Regulation Mode | variable-frequency-control-type and program-control-type stepless speed regulation; manual or automatic timed; positive or negative revolving |
| Max. continuous operating time full-load) |
72 hours |
Features————————
1. Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.
2. Planetary movement principle is adopted in the machine, which has high speed, large energy, high efficiency, small Granularity.
3. Four powder samples from different sizes and different materials can be produced at one time.
4. The machine is controlled by frequency converter, you may choose ideal rotating speed according to expected experimental result. The converter is equipped with device of under voltage and over-current to protect the motor.
5. The planetary ball mill has functions of timing power off, self-timing forward and reversal rotating. You may choose freely any operation modes of one-way direction, alternation, succession, time setting according to experimental needs, so as to improve efficiency of grinding.
6. Technical features of Tencan Ball Mill: Low center of gravity, stable performance, compact structure, easy operation, reliable safety, lower noise, small loss.
7. Safety switch is installed on the machine to prevent safety accident if the safety cover is opened while machine is running.
Types for Planetary Ball Mill————————
| Model | Specification | Spec(ml,L) | Quantity (Set) |
|---|---|---|---|
| KD-XQM-0.4L |
0.4L |
50-100ml | 4 mill tanks |
| KD-XQM-1L | 1L | 50-250ml | 4 mill tanks |
| KD-XQM-2L |
2L |
560-500ml | 4 mill tanks |
| KD-XQM-4L | 4L | 50-1000ml | 4 mill tanks |
| KD-XQM-8L | 8L | 0.5-2L | 4 mill tanks |
| KD-XQM-12L | 12L | 1-3L | 4 mill tanks |
| KD-XQM-16L | 16L | 1-4L | 4 mill tanks |
Package & Shipping————————
Package Type:
PE Form + Cartons / Woodern cases;
Can be dispatched according to customr's requirement
Port:
Shanghai Port, Guangzhou Port, Tianjin Port, Qingdao port.
Delivery time:
Within 3-7 working days from the date of payment receipt
Factory————————
FAQ————————
1.Q: What is the size in your products?
A: The minimum type is 0.4L planetary ball mill Model XQM-0.4A in size of 53*30*34cm, machine weight 26kgs. We have other types from 0.2-100L to 100L for your options.
2.Q: What is your terms of delivery?
A: FOB, CFR, CIF.
3.Q: Can you accept small quantity sample order before production?
A: Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.
4.Q: What is your production time?
A: Generally, it will take 3-7 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
5.Q: What is your terms of payment?
A: T/T 30% as deposit, 70% balance against the copy of original B/L. Or 100% L/C at sight. We'll show you the photos of the products and the copy of original B/L before you pay the balance.
6.Q: What is the working principle of planetary ball mill?
A: Please refer to this news: China Hunan jingshengda ceramic technology Co.,ltd latest company news about Working principle of planetary ball mill (ecer.com)
